Seeder Anti-reverse Drive Pto Shaft 04B-RLPx80CM

Yoke:Splined yoke / Plain Bore yoke / Tube yoke

Tube:Triangle /Lemon /Star /Involute Spline Tube

Yoke Processing:Forging or Casting

Plastic Guard:130/160/180 series

Color:yellow black etc.

Send email to us

Product Detail

Model						Supporting horsepower (H.P)	Torque (Nm)	International Reference Examine the model Code




	D×L (Cross)	h×s (Inner)	Code	H×S (Outer)	Code

025B	22×54	26.6×3.5	002	32.4×2.5	003	12-18	175-215	T1
	22×55
03B	24×63	29×4	004	36.1×3.4	005	20-30	250-300	T2
	23.8×61.3
035B	27×70	36.1×4	007	43.4×3.3	008	25-35	330-420	T3

04B	27×74.5					25-45	380-500	T4
042B	27×81.7	44.7×4	009	51.3×3	010012	35-55	420-600

045B	30.2×80					40-60	450-650	T5
047B	30×88					40-60	450-650

05B	30.2×92	44.7×4	009	53.6×3.8	012	40-65	700-900	T6
06B	30.2×106.3					55-80	800-1000	T7
062B	32×76					50-80	800-1000
063B	32×92					50-80	900-1200

	32×94
064B	35×94					55-90	900-1200	T7N
065B	35×98					65-100	1000-1300
068B	36×89					65-100	1000-1300

07B	35×106.3	44.7×5.5	011	53.6×3.8	012	65-100	1000-1300	T8
073B	38×102.3					70-120	1250-1800
075B	39×95	53.6×5	013	62.7×4	022	70-120	1250-1800
08B	39×118					80-150	1500-2000
083B	41×108					90-180	1600-2000	T9

084B	41×118					100-220	1700-2200	T10
085B	42×104					120-250	1800-2500
